Specifications :
- 8-channel mixer
- Microphone inputs in 2 types, Canon and standard
- 4 free AUX inputs
- Recording input and output (RCA)
- Output (OUT) for connection to another amplifier or active speaker
- 100 effect programs
- Light display (LEVEL METER)
- 4 separate amplifier channels (450+450+450+450 watts)
- 3-speaker digital equalizer with memory for each amplifier channel separately
- Automatic cooling fan system
- Equipped with short circuit, overload, and DC output voltage protection
- Special terminals for connecting to effect devices with volume control
- Equipped with: MP3 player - Radio Equalizer - Recorder - FM
Technical Specifications :
| System Type |
Amplifier |
| Power |
1900 W |
| Amplifier |
4 channels (450W + 450W + 450W + 450W) |
| Mixer |
8 channels with 3-speaker equalizer |
| Microphone Input |
12 microphone inputs (8 mono jack inputs + 5 XLR Canon jack inputs) |
| Free Input |
4 free AUX mono jack inputs |
| Equalizer |
3-speaker digital |
| Microphone Input Sensitivity and Impedance |
-60 dB , 4.7 kΩ |
| AUX Input Sensitivity and Impedance |
-30 dB , 100 kΩ |
| Input Noise Balance Ratio |
-120 dB |
| Signal-to-Noise Ratio |
>98 dB |
| Distortion |
>0.005% |
| Treble Frequency Control |
±15dB در 15 KHz |
| Midrange Frequency Control |
±15dB در 1.5 KHz |
| Bass Frequency Control |
±15dB در 60 Hz |
| Recording Input |
-22 dB |
| Recording Output |
-10 dB |
| Delay Time |
100 ms - 1000 ms |
| Output Signal-to-Noise Ratio |
108 dB |
| Digital Effects |
100 Programs |
| Reverb |
1 sec. - 10 sec. |
| Dimensions |
W36 - D60 - H37.5 Cm |
| Weight |
18.7 Kg |
| MP3 |
✓ |
| Radio |
✓ |
| Bluetooth |
✓ |
|
USB
|
✓ |
| Mointor out |
✓ |
